S-Works Crux 5 Frameset

Name: Specialized S-Works Crux 5 Frameset
Brand: Specialized
SKU: 210000138376
Price: 7500.0 CAD
Availability: OutOfStock

$7,500.00

The S-Works Crux 5 is a gravel racing frameset built around FACT 12r carbon construction. Weighing just 789 grams, the frame pairs with an S-Works FACT Carbon fork to keep overall frameset weight at 1.63 kg. A threaded bottom bracket shell and UDH dropout provide broad drivetrain compatibility across a range of gravel race builds.

The frameset runs a 12x142mm rear thru-axle and flat-mount disc interface, with the fork matching via a 12x100mm thru-axle. The included S-Works Tarmac SL8 carbon seatpost offers a 15mm offset and lightweight saddle clamp, while an integrated wedge seat binder keeps the cockpit tidy and reduces external hardware at the seat tube.

Quick Facts

Feature	Specification
Frame Material	FACT 12r Carbon
Claimed Frame Weight	789 grams
Claimed Frameset Weight	1.63 kg (size 56)
Bottom Bracket	68mm BSA Threaded
Rear Axle	12x142mm thru-axle
