34 Damper Grip X2: 2025 34 140, Grip X2 HSR / LSR / HSC/ LSC , CFBV, CM, RM,
The Fox 34 GRIP X2 Damper Upgrade Kit brings Fox's 4-way adjustable damper to compatible 34mm forks, replacing the stock cartridge with independent high speed and low speed compression and rebound circuits. Riders gain separate control over small-bump sensitivity and big-hit support, letting the fork be tuned for a wide range of trail conditions without compromising either end of the spectrum.
Inside, the GRIP X2 cartridge uses a 24mm base valve and 23 shims, more than three times the hardware found on a GRIP2 unit, for finer damping resolution. The kit fits any 2016-or-newer Fox 34 fork aside from Rhythm and Step-Cast models, with travel capped at 140mm on 29-inch wheels or 150mm on 27.5-inch wheels. A full service, using Fox 4WT suspension fluid, is recommended every 125 hours.
Quick Facts
| Feature | Specification |
|---|---|
| Damper Type | GRIP X2, 4-way adjustable (HSC, LSC, HSR, LSR) |
| Base Valve | Oversized 24mm, 23 shims |
| Compatibility | 2016-or-newer Fox 34 forks, excluding Rhythm and Step-Cast |
| Max Travel | 140mm (29-inch wheel), 150mm (27.5-inch wheel) |
| Service Interval | Full service every 125 hours, using Fox 4WT suspension oil |
